453564081701 PHiliph VM6 Patient Monitor Parts Keypress Encoder Board

453564081701 PHiliphhilip VM6 Patient Monitor Keypress Encoder Board

About the keypress /Navigation Wheel

The Navigation Wheel is a push-button rotary wheel. The associated wheel circuit generates a pulse when pressed and produces a digital encoding of a pair of quadrature signals whose relative amplitude and polarity represent the angular position of the wheel. These outputs are connected to the µProcessor, where they are interpreted as required by the relevant functions. Successive angular positions determine the direction of rotation of the wheel. In addition to the functions performed with the keypad, the scroll wheel works with the display to select menus and lists of parameter variables.

Removing keypress encoder board

• 1. Separate the front and rear monitor case assemblies
• Remove the LCD display
• Pull the wheel off of the stem.

• Remove the locking nut and washer with a 10 mm wrench

• Remove the Torx T10 self-tapping screw

• Press the stem while lifting off the wheel assembly

Note — When you reattach the wheel, line up the flat side of the wheel to the flat side of the metal wheel stem

Warranty

We offer a 90 day warranty. If you have any after-sales problems, please feel free to contact us. But before purchasing and shipping, it will help our technician to check all products carefully. Must buy.

How to place order ?

Check out all the details of the sale first. Form Invoices are sent within 3-5 business days of payment after confirmation and delivery assistance. T/T, Paypal, Western Union accepted. It takes about 5 working days to arrive at the customer. After payment.

Advantage

1.Sufficient inventory is provided. We use patient monitors, defibrillators, ECG/ECG devices, cables, batteries, Spo2 sensors, hard paddles, etc. from various brands (PHiliphhilip, Mindray, Goldway, GE, Zoll, Masima, Nihon KONKEN, etc.). If you need it, please feel free to contact us.

2. Our engineers have more than 12 years experience in this field. Whatever problem you encountered, please contact us. We will provide services based on our professional experience.

3. Easy export. We are located in Guangzhou city, the largest export city of China.

4. Fast delivery time. We can ship within 3-5 business days and take about 5 business days to arrive.

FAQ :

• How fast can i receive my order?

Usually around 5-7 working days .

• Can i return back withing 30 days if it doesn’t work ?

Sure .We have 90 days warranty .

• Can i order one sample firstly?

Of course,our MOQ is one piece .It’s totally okay to order one sample to test .

• What’s your payment terms ?

Full before shipment .Even our VVIP customers pay full before shipment .
